| Heatsink Specifications | |
| Dimension | L120 mm x W46 mm x H148 mm |
| Weight | 630g |
| Heat pipes | 6mm heatpipe x 4 units |
| Fin | T = 0.4 mm；Gap=1.6 mm |
| Fin pcs | 51 pcs |
| TL-C12C FAN Specifications | |
| Dimension | L120 mm x W120 mm x H25 mm |
| Rated Speed | 1550 RPM±10% (MAX) |
| Noise Level | 25.6 dBA |
| Air Flow | 66.17 CFM (MAX) |
| Air Pressure | 1.53mm H2O (MAX) |
| Ampere | 0.20 A |
| Connector | 4 Pin (PWM Fan connector) |
| Bearing Type | S-FDB Bearing |
