Thông tin chung:
|Loại sản phẩm||Mainboard - Bo mạch chủ|
|CPU hỗ trợ|
Intel® Socket LGA1200 for 11th Gen Intel® Core™ processors & 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors
|Chipset||Intel® Z590 Chipset|
|RAM hỗ trợ|
4 x DIMM, Max. 128GB, DDR4 5333(OC)
Non-ECC, Un-buffered Memory*
1 x DisplayPort 1.4**
* Graphics specifications may vary between CPU types.
"** For Intel® 11th Core™ i5/ i7/ i9 processors, support DisplayPort 1.4 with max. resolution of 5120 x 2880 @60Hz, others would only support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz .Please refer to www.intel.com for any update.
Please refer to www.intel.com for any update. "
*** For Intel® 11th Core™ i5/ i7/ i9 processors, support HDMI™ 2.0 with max. resolution of 4K@60Hz, others would only support HDMI™ 1.4 with max. resolution of 4K@30Hz .Please refer to www.intel.com for any update.
**** VGA resolution support depends on processors' or graphic cards' resolution.
|Khe cắm mở rộng|
3 x PCIe 4.0/3.0 x16 (x16, x8/x4/x4)
Intel® 11th &10th Gen Processors
|Ổ cứng hỗ trợ|
Supports 3 x M.2 slots and 6 x SATA 6Gb/s ports
Intel®11th Gen Processors
M.2_1 slot (Key M), type 2242/2260/2280/22110
Intel® Z590 Chipset
M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)*
M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)**
6 x SATA 6Gb/s ports
Raid function in Intel® Rapid Storage Technology is available with either 1. Intel® SSDs installed in both CPU-attached and PCH-attached slots, or 2. any other 3rd party SSDs installed in PCH-attached slots.
To enable Intel® Optane™ Memory (Hybrid Storage device), it must be installed in PCH-attached slots with Intel® Rapid Storage Technology.
*When M.2_2 is operating in SATA device, SATA6G_2 will be disabled.
|LAN||1 x Intel® I225-V 2.5Gb Ethernet|
Rear USB: Total 10 ports
1 x USB 3.2 Gen 2x2 port(s) (1 x USB Type-C®)
1 x USB 3.2 Gen 1 connector(s) (support(s) USB Type-C®)
|Âm Thanh||"ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080|
- Impedance sense for front and rear headphone outputs
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
- Supports up to 32-Bit/384 kHz playback"
- SupremeFX Shielding Technology
- ALC4080 + Savitech SV3H712 AMP
- audio jacks
- Rear audio USB Type-C® port
- Premium Japanese audio capacitors
- Audio cover
Cổng kết nối (I/O Phía sau)
|1 x USB 3.2 Gen 2x2 port(s) (1 x USB Type-C®)|
4 x USB 3.2 Gen 2 port(s) (4 x Type-A)
5 x USB 2.0 port(s) (4 x Type-A, 1 x Audio USB Type-C®)
1 x HDMI™ port
1 x DisplayPort
1 x ASUS Wi-Fi Module
1 x Intel® I225-V 2.5Gb Ethernet
5 x Audio jacks
1 x BIOS FlashBack™ button
|Cổng kết nối (I/O bên trong)|
1 x Thunderbolt 4 header
Fan and Cooling related
|BIOS||256 Mb Flash ROM, UEFI AMI BIOS|
|Khả năng quản lý||WOL by PME, PXE|
|Kích cỡ||ATX Form Factor|
12 inch x 9.6 inch (30.5 cm x 24.4 cm)
