- Precision resized 45.38L chassis offers expanded hardware support with a compact footprint
- Pillar-less tempered glass front and side panels for an unobstructed internal view
- 10° slanted bottom improves GPU airflow and aesthetic presentation
- Supports ATX, M-ATX, Mini-ITX, and ATX Back-Connect motherboards
- Accommodates 400mm long GPUs, 160mm tall CPU coolers, and ATX PSU (Under 200mm)
- Supports up to 360mm top radiator, 240mm side radiator, and 9 x 120mm fans
- Includes horizontal and vertical GPU anti-sag brackets for heavy GPU support
| PRODUCT NAME | O11D MINI V2 | |||
|---|---|---|---|---|
| MODEL NO. | O11DMIV2X | O11DMIV2W | ||
| COLOR | BLACK | WHITE | ||
| DIMENSIONS | 423.6mm x 273.3mm x 391.95mm (DxWxH) | |||
| MATERIALS | 2mm Aluminum Panel / 1mm Mesh Panel / 4.0mm Tempered Glass | |||
| MOTHERBOARD SUPPORT | Back-Connect ATX ATX / Micro-ATX / Mini-ITX | |||
| EXPANSION SLOT | 5 | |||
| STORAGE | Drive Cage: 2.5” SSD x 2 or 3.5” HDD x 2 Behind MB Tray: 2.5″ SSD x 2 | |||
| GPU LENGTH CLEARANCE | 400 mm | |||
| CPU COOLER HEIGHT CLEARANCE | 160 mm | |||
| PSU SUPPORT | ATX (Under 200mm) | |||
| RADIATOR SUPPORT | Top: 240mm / 280mm / 360mm (Note: 280mm radiator requires mounting motherboard one slot lower) Side: 240mm | |||
| FAN SUPPORT | Top: 120mm x 3 or 140mm x 2 Side: 120mm x 2 Bottom: 120mm x 3 Rear: 120mm x 1 | |||
| INCLUDED FANS | N/A | |||
| DUST FILTER | Bottom x 1 | |||
| I/O PORTS | USB 3.0 x 2 USB 3.2 Type C x 1 Audio x 1 Power Button x 1 | |||
