Chipset: Intel B860
Socket: Intel LGA 1851
Kích thước Main: M-ATX
Hỗ trợ CPU: Support Intel® Core™ Ultra Processors (Series 2) , LGA1851
Khe cắm RAM: 2 khe ram
Loại RAM: DDR5
| Chipset | Intel B860 |
| Socket | Intel LGA 1851 |
| Kích thước Main | M-ATX |
| Hỗ trợ CPU | Support Intel® Core™ Ultra Processors (Series 2) , LGA1851 |
| Khe cắm RAM | 2 khe ram |
| Loại RAM | DDR5 |
| Bus RAM hỗ trợ | 2 x DIMM slots, max. 128GB, DDR5 Supports up to 6400MT/s, Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM) Dual channel memory architecture Supports DIMM Fit and DIMM Fit Pro Supports Intel® Extreme Memory Profile (XMP) memory module ASUS Enhanced Memory Profile II (AEMP II) |
| Chi tiết Vga | 1 x VGA port 1 x HDMI™ port |
| Kết nối mạng | 2.5 Gigabit LAN 10/100/1000/2500 Mb/s |
| Thông số (Lan/Wireless) | 1 x Realtek 2.5Gb Ethernet |
| Khe cắm trong | Intel® Core™ Ultra Processors (Series 2) 1 x PCIe 4.0 x16 slot Intel® H810 Chipset 1 x PCIe 4.0 x1 slot - To ensure compatibility of the device installed, please refer to https://www.Asus.Com/support/download-center/ for the list of supported peripherals. |
| Khe cắm mở rộng | Total supports 1 x M.2 slot and 4 x SATA 6Gb/s ports Intel® H810 Chipset M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) 4 x SATA 6Gb/s ports |
| Cổng giao tiếp ngoài | 2 x USB 5Gbps ports (2 x Type-A) 4 x USB 2.0 ports (4 x Type-A) 1 x VGA port 1 x HDMI™ port 1 x Realtek 1Gb Ethernet port 3 x Audio jacks 1 x PS/2 keyboard/mouse combo port |
| Âm thanh | Realtek 7.1 Surround Sound High Definition Audio CODEC |
