Thông số kỹ thuật
Empower your desktop with this incredibly powerful and versatile compact PC. The all-new MAGNUS ONE retains the 8.3 liter chassis of its predecessor, but the internals have been thoroughly upgraded with cutting-edge hardware, including a 13th gen Intel® Core™ i5 processor for faster processing, a ZOTAC GAMING GeForce RTX™ 4060 graphics card for high-fidelity ray-traced graphics and AI-accelerated features such as DLSS3.5, and other upgrades such as a UHS-II card reader for faster file transfers from SD cards. Pair those with upgradable memory and storage and a full-range of connectivity options, and you have a capable machine that could deliver the best experience for daily tasks, gaming, entertainment, content creation and business.
- 8.3 liter compact chassis
- 13th Gen Intel Core i5 processor
- ZOTAC GAMING GeForce RTX 4060 8GB GDDR6
- 2 x DDR5-4800 SODIMM Memory Slots (up to 64GB)
- 2 x M.2 SSD slots, 1 x 2.5-inch SATAIII HDD/SSD bay
- 1 x HDMI 2.1a, 3 x DisplayPort 1.4a, 1 x HDMI 1.4 (integrated)
- 4 x USB 3.1 GEN2, 4 x USB 3.0 (1 Type-C)
- 1 x Thunderbolt 4, 1 x UHS-II SDHC/SDXC Card Reader
- WiFi 6, Gigabit and 2.5Gbps Ethernet
- 500W 80+ Platinum power supply ( PSU Flex )
- Creator Ready / 4K Ready / Gaming Ready / VR Ready
CHI TIẾT KỸ THUẬT SẢN PHẨM
Xem chi tiết
Cấu hình hệ thống
CPU
Intel Core i5-13400 (10-core 1.8 GHz, up to 4.6 GHz)
Chipset
Intel, NVIDIA
Dung lượng RAM
2 x DDR5-4800 SODIMM Memory Slots (up to 64GB)
Đồ họa
Công nghệ
ZOTAC GAMING GeForce RTX 4060 8GB GDDR6 128-bit
Cổng xuất hình
1 x HDMI 1.4 (up to 3840x2160@30Hz) (integrated)
3 x DisplayPort 1.4a (up to 7680x4320@60Hz)
1 x HDMI® Connector*
*Supports 4K 120Hz HDR, 8K 60Hz HDR, and Variable Refresh Rate as specified in the HDMI 2.1a Specification
Up to 4 Displays
Lưu trữ
Ổ cứng
1 x 2.5“ SATAIII HDD/SSD bay
Bộ nhớ đệm
N/A
Ổ quang
N/A
mSATA
N/A
M.2
1 x M.2 PCIe 4.0 x4 NVMe / SATA SSD slot (2242/2280) , 1 x M.2 PCIe 4.0 x4 NVMe SSD slot (2242/2280/22110)
Đầu đọc thẻ nhớ
3-in-1 (UHS-II SD/SDHC/SDXC)
Cổng I/O
Âm thanh
Microphone Headphone Combo Jack, 8ch via HDMI
Cổng USB
4 x USB 3.1
4 x USB 3.0 (1 Type-C)LAN
Dual LAN (Gigabit Ethernet, 2.5Gbps Ethernet)
Ăng-ten
Dual WiFI SMA connetor
Wifi
WiFi 6
Bluetooth
Bluetooth 5.2
Legacy I/O
N/A
Cổng hồng ngoại
N/A
Thunderbolt
1 x Thunderbolt 4
USB
N/A
IDE
N/A
VGA
N/A
Mechanical
Khóa Kensington
Yes
Đèn LED
Power, HDD, WiFi
Nguồn
500W 80+ Platinum
Hệ thống tản niệt
Fan + Heatsink
Kích cỡ ZBOX
265.5mm x 126mm x 249mm (10.45in x 4.96in x 9.8in)
