| Bảo hành | 60 tháng |
MORE SPECS
Model Code (Capacity)1)
- MZ-V8V250BW (250GB)
- MZ-V8V500BW (500GB)
- MZ-V8V1T0BW (1TB)
General Feature
- APPLICATION
Client PCs
- FORM FACTOR
M.2 (2280)
- INTERFACE
PCIe Gen 3.0 x4, NVMe 1.4
- DIMENSION (WxHxD)
80.15 x 22.15 x 2.38 (mm)
- WEIGHT
Max 8.0 g
- STORAGE MEMORY
Samsung V-NAND 3-bit MLC
- CONTROLLER
Samsung Pablo Controller
- CACHE MEMORY
HMB(Host Memory Buffer)
Special Feature
- TRIM SUPPORT
Supported
- M.A.R.T SUPPORT
Supported
- GC (GARBAGE COLLECTION)
Auto Garbage Collection Algorithm
- ENCRYPTION SUPPORT
AES 256-bit Encryption (Class 0)
TCG/Opal IEEE1667 (Encrypted drive)
- WWN SUPPORT
Not Supported
- DEVICE SLEEP MODE SUPPORT
Yes
Performance2)
- SEQUENTIAL READ
250GB: Up to 2,900 MB/s
500GB: Up to 3,100 MB/s
1TB: Up to 3,500 MB/s
- SEQUENTIAL WRITE
250GB: Up to 1,300 MB/s
500GB: Up to 2,600 MB/s
1TB: Up to 3,000 MB/s
- RANDOM READ (4KB, QD32)
250GB: Up to 230,000 IOPS
500GB: Up to 400,000 IOPS
1TB: Up to 500,000 IOPS
- RANDOM WRITE (4KB, QD32)
250GB: Up to 320,000 IOPS
500GB: Up to 470,000 IOPS
1TB: Up to 480,000 IOPS
- RANDOM READ (4KB, QD1)
250GB: Up to 17,000 IOPS
500GB: Up to 17,000 IOPS
1TB: Up to 17,000 IOPS
- RANDOM WRITE (4KB, QD1)
250GB: Up to 53,000 IOPS
500GB: Up to 54,000 IOPS
1TB: Up to 54,000 IOPS
Environment
- AVERAGE POWER CONSUMPTION
(SYSTEM LEVEL)3)
250GB: Average 3.7 W Maximum 5.6 W (Burst mode)
500GB: Average 4.3 W Maximum 5.9 W (Burst mode)
1TB: Average 4.6 W Maximum 5.3 W (Burst mode)
- POWER CONSUMPTION (IDLE)3)
Max. 45 mW
- POWER CONSUMPTION (DEVICE SLEEP)
Max. 5 mW
- ALLOWABLE VOLTAGE
3.3 V ± 5 % Allowable voltage
- RELIABILITY (MTBF)
1.5 Million Hours Reliability
- OPERATING TEMPERATURE
0 - 70 ℃
- SHOCK
1,500 G & 0.5 ms (Half sine)
Accessories
- INSTALLATION KIT
Not Available
Software
- INSTALLATION KIT
Magician Software for SSD management
Warranty
- MZ-V8V250BW (250GB)
5 Years or 150 TBW
- MZ-V8V500BW (500GB)
5 Years or 300 TBW
- MZ-V8V1T0BW (1TB)
5 Years or 600 TBW
