| CPU Compatibility | Intel LGA2066/2011/1150/1151/1155/1156/775/1366 |
| AMD AM4/FM2+/FM2/FM1/AM3+/AM3/AM2+/AM2 |
| TDP | 145W |
| Overall Dimension | 135(L)X80(W)X146(H)mm |
| Heatsink Material | Aluminum |
| Heat Base Material | 45X38mm HDT(Heat pipes Direct Touch) |
| Heat Pipes | 4X6mm Copper powder heat pipes |
| Surface Treatment | Anti-oxidation Protective Layer |
| Weight/Loading | 860g 555*420*370mm 24Pcs /CTN |
| RGB Version | Fixed LED Color Fan |
| Fan Dimension | 120×120×25mm |
| Included Fans | 1pcs |
| Fan Speed | 800~1600±10%RPM |
| Max. Air Flow | 65.4CFM |
| Max. Static Pressure | 2.05mmH2O |
| Noise | 18~30 dB(A) |
| Rated Voltage | 12VDC |
| Operating Voltage | 6~13.8VDC |
| Started Voltage | 7.5VDC |
| Rated Current | 0.1~0.4A ± 0.02A(Fan Moto) |
| powder Input | 5.5W |
| Bearing Type | Hydraulic Bearing |
