Specification:
CPU Block Info
- Cold Plate Material: Copper
- Block Dimensions; (A) 74 x (B) 69.1 x (C) 62.45 mm
- Cold Plate Dimensions; Φ64*4.35T
- Intel Socket: LGA 1150/1151/1155/1156/1200/1700
- AMD Socket: AM5/AM4
- Block Lighting: ARGB GEN2
Pump Info
- Pressure Head: 161 cmH2O
- Q-Max: 55L/ H
- Pump Life Expectancy; 50,000 hours in typical use
- Pump Noise Level: 20 dBA (avg.)
- Pump Load Current: 0.33A (Max: 0.5A)
- Pump Power Consumption: 3.96W (Max: 6W)
- Pump Speed: 3400 RPM ± 10%
- Pump Connector
- PWM 4-PIN Header
- 5V ARGB 3pin Header ( Female )
- 5V ARGB 3pin Header ( male )
Radiator Info:
- Radiator Size; 360 mm
- Radiator &Fan Dimensions: (A) 394 x (B) 125.6 x (C) 52.6 mm / 15.51 x 4.96 x 2.04 inches
- Radiator Material: Aluminum
- Water Cooling Tube Material: EPDM
- Water Cooling Tube Length: 400mm / 15.75 inches
Fan Info:
- Number of Fans: 3
- Fan Dimensions: 120 x 120 x 25 mm / 4.7 x 4.7 x 0.98 inches
- Fan Speed: 2350±10%RPM
- Fan Air Flow: 70.7 CFM
- Fan Noise Level: 32.8 dBA
- Fan Static Pressure: 3.651 mmH2O
- Fan Bearing: Loop Dynamic Bearing(LDB)
- Fan Life Expectancy: 30,000 hrs@40℃
- Fan Rated Current: 0.2A(Max:0.3A)
- Fan Power Consumption: 2.4W(Max:3.6W)
- PWM Mode: Yes
- Cable Length: (5V ARGB / PWM cable) 550 / 500 mm; 21.65 / 19.69 inches
- Fan Lighting: ARGB GEN2 Connector 5V ARGB 3pin Header / PWM 4pin Header
