Graphic Engine
NVIDIA® GeForce RTX™ 5090
AI Performance
3352 TOPs
Bus Standard
PCI Express 5.0
OpenGL
OpenGL®4.6
Video Memory
32GB GDDR7
Engine Clock
OC mode: 2760 MHz
Default mode: 2730 MHz(Boost clock)
CUDA Core
21760
Memory Speed
28 Gbps
Memory Interface
512-bit
Resolution
Digital Max Resolution 7680 x 4320
Interface
Yes x 2 (Native HDMI 2.1b)
Yes x 3 (Native DisplayPort 2.1b)
HDCP Support Yes (2.3)
Maximum Display Support
4
NVlink/ Crossfire Support
No
Accessories
1 x Detachable AMOLED Display
1 x Detachable Glass Backplate
1 x Detachable GC-HPWR Adapter
1 x ROG Edition 20 Graphics Card Holder
1 x ROG Velcro Hook & Loop
1 x ROG Magnet
1 x ROG Graphics Card Keycap
1 x ROG PCB Ruler
1 x ROG Edition 20 Thank You Card
1 x ROG Edition 20 Sticker
1 x ROG Edition 20 Collective Coin
1 x Adapter Cable (1 to 4)
1 x USB Adapter Cable (Type-A to Type-C)
1 x Speedsetup Manual
Software
ASUS GPU Tweak III & MuseTree & GeForce Game Ready Driver & Studio Driver: please download all software from the support site.
Dimensions
361 x 139.3 x 93.9 mm
14.21 x 5.48 x 3.7 inches
Recommended PSU
1200W+
Power Connectors
1 x 16-pin, Graphics card high-power (GC-HPWR) gold finger
Slot
4.7 slot
AURA SYNC
ARGB
Hidden-connector (BTF)
With Graphics card high-power gold finger
Note
* Our wattage recommendation is based on a fully overclocked GPU and CPU system configuration. For a more tailored suggestion, please use the “Choose By Wattage” feature on our PSU product page: https://rog.asus.com/event/PSU/ASUS-Power-Supply-Units/index.html
* All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets. If you do not use the latest and current specifications of ASUS products, you shall be liable for all loss and damage claimed by third party to ASUS based on false advertising or any other issues caused from using false specifications of ASUS products.
* Maximum Display Support is specifically applied to simultaneous display situation.
