- Support MB Form Factor
- Case Form Factor
- Product Name
- Dimension
- I/O Ports
- Driver Bays
- Case Expansion Slots
- Pre-install Fan
- RADIATOR LAYOUT
- Fan Support
- Maximum PSU Length
- Maximum GPU Length
- Maximum CPU Cooler Length
- Lightning
- Power Supply
Regular: ATX / Micro-ATX / Mini-ITX
Back-connect: ATX / Micro-ATXMid Tower
MAG PANO 100R PZ
518.7 x 290 x 482 mm / 20.42 x 11.42 x 18.98 inches
1 x USB 20Gbps Type-C
2 x USB 5Gbps Type-A
1 x Audio-Out / Mic-in
1 x LED Switch Button
1 x Power Button3 x 2.5”
2 x 2.5”/3.5” combo8
Side: 3 x 120 mm
Rear: 1 x 120 mmTop: 120 / 240 / 360 mm
Front: NA
Rear: 120 mm
Side: 120 / 240 / 360 mm
Bottom: 120 / 240 / 360 mmTop: 3 x 120 mm / 3 x 140 mm
Front: NA
Rear: 1 x 120 mm
Side: 3 x 120 mm / 2 x 140 mm
Bottom: 3 x 120 mm / 2 x 140 mm / 2 x 160 mm200 mm / 7.87 inches
380 mm / 14.96 inches
166 mm / 6.54 inches
Side: 3 x ARGB Reverse-blade
Rear: 1 x ARGBATX
Connection
- 1x USB 3.2 Gen 2x2 Type-C
- 2x USB 3.2 Gen 1 Type-A
- Mic In/ Audio Out
- LED Switch Button
- Power Button
