Graphics Engine
- AMD Radeon™ RX 7800 XT
Bus Standard
- PCI® Express 4.0 x16
DirectX
- 12 Ultimate
OpenGL
- 4.6
Memory
- 16GB GDDR6
Engine Clock
- Boost Clock*: Up to 2520 MHz
- Game Clock**: 2213 MHz
*Boost Clock is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.
**Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.Stream Processors
- 3840
Memory Clock
- 19.5 Gbps
Memory Interface
- 256-bit
Resolution
- Digital Max Resolution: 7680 x 4320
Interface
- 3 x DisplayPort™ 2.1*
- 1 x HDMI™ 2.1
*DisplayPort (DP) 2.1 on any one or two ports. DisplayPort (DP) 1.4a on any and up to 3 ports simultaneously.
HDCP
- Yes
Multi-view
- 4
Recommended PSU
- 800W
Power Connector
- 2 x 8-pin
Accessories
- 1 x Quick Installation Guide
Dimensions
- 304 x 131 x 56 mm, 2.8-slot
Net Weight
- 1242 g
