ROG Strix LC GeForce RTX™ 3090 Ti OC Edition 24GB GDDR6X reigns supreme by combining liquid cooling with the NVIDIA Ampere architecture.
- NVIDIA Ampere Streaming Multiprocessors: The all-new Ampere SM brings 2X the FP32 throughput and improved power efficiency.
- 2nd Generation RT Cores: Experience 2X the throughput of 1st gen RT Cores, plus concurrent RT and shading for a whole new level of ray-tracing performance.
- 3rd Generation Tensor Cores: Get up to 2X the throughput with structural sparsity and advanced AI algorithms such as DLSS. These cores deliver a massive boost in game performance and all-new AI capabilities.
- G6X Memory: This is the world’s fastest graphics memory on the GeForce RTX 3090 Ti.
- 8K HDR Gaming GPU, Powered by AI: The GeForce RTX 3090 Ti lets you play, capture, and watch your games in brilliant 8K HDR. It features DLSS 8K gaming, GeForce Experience support for 8K HDR game capture, and AV1 decode for efficient playback of 8K HDR streamed video.
- OC edition: Boost clock 1980 MHz (OC mode)/ 1950 MHz (Gaming mode)
- Full-coverage cold plate brings liquid cooling to GPU die and memory.
- On-board cooling for power-delivery is handled by a blower-style fan and low-profile heatsink.
- 240mm radiator balances compatibility and performance.
- 560mm tubing for compatibility with EATX chassis and alternative mounts.
ROG Strix LC GeForce RTX 3090 Ti OC Edition
Graphic Engine
NVIDIA® GeForce RTX™ 3090 Ti
Bus Standard
PCI Express 4.0
OpenGL
OpenGL®4.6
Video Memory
24GB GDDR6X
Engine Clock
OC mode: 1980 MHz(Boost Clock) Gaming mode: 1950 MHz(Boost Clock)
CUDA Core
10752
Memory Speed
21 Gbps
Memory Interface
384-bit
Resolution
Digital Max Resolution 7680 x 4320
Interface
Yes x 2 (Native HDMI 2.1)
Yes x 3 (Native DisplayPort 1.4a)
HDCP Support Yes (2.3)
Maximum Display Support
4
NVlink/ Crossfire Support
Yes
Accessories
1 x ROG Velcro Hook & Loop 1 x Collection card 1 x Speedsetup Manual 1 x 16-pin to 8-pin Adapter Cable
Software
ASUS GPU Tweak II & GeForce Game Ready Driver & Studio Driver: please download all software from the support site.
Dimensions
Card: 293 x 133 x 52 mm Radiator: 272 x 121 x 54 mm
Recommended PSU
1000W
Power Connectors
1 x 16-pin
Slot
2.6 Slot
Note
* Our wattage recommendation is based on a fully overclocked GPU and CPU system configuration. For a more tailored suggestion, please use the “Choose By Wattage” feature on our PSU product page: https://rog.asus.com/event/PSU/ASUS-Power-Supply-Units/index.html
