Tên mẫu | RT-AX59U |
Network Standard | IEEE 802.11a IEEE 802.11b IEEE 802.11g WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax) IPv4 IPv6 |
Product Segment | AX4200 ultimate AX performance: 574+3603 Mbps |
WiFi Data Rate | 802.11a : up to 54 Mbps 802.11b : up to 11 Mbps 802.11g : up to 54 Mbps WiFi 4 (802.11n) : up to 450 Mbps WiFi 4 (802.11n) (256QAM) : up to 600 Mbps WiFi 5 (802.11ac) : up to 2600 Mbps WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps WiFi 6 (802.11ax) (5GHz) : up to 3603 Mbps |
Antenna | Internal antenna x 5 |
Transmit / Receive | MIMO technology 2.4GHz 2×2 5GHz 3×3 |
Processor | 2.0GHz quad-core 64bit processor |
Memory | 128 MB Flash 256 MB RAM |
Boosts Speed | OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 1024-QAM high data rate 20/40/80/160 MHz bandwidth |
Operating Frequency | 2.4G Hz / 5 GHz |
Operating Mode | Router(AiMesh router), AiMesh node, Access point, Repeater, Media bridge |
I/O Ports | RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 3 USB 3.2 Gen 1 x 1, USB 2.0 x 1 |
Buttons | WPS Button, Reset Button, Power Switch |
LED Indicator | Power & Status Combo LED x 1 |
Power Supply | AC Input : 110V~240V(50~60Hz) DC Output : 12 V with max. 2.5 A current |
Package Content | RT-AX59U Router RJ-45 cable Power adapter Warranty card Quick start guide |
Product Weight (g) | 476 g |
Product Dimensions | 131 x 37.5 x 200 mm (WxDxH) |
Remark | Content and color may vary in different regions and packages. |
AiMesh | AiMesh • Primary AiMesh Router • AiMesh Node |
Parental Control | “Allow you to block access to unwanted websites and apps.” Safe Browsing Customized Internet Schedule • Maximum Parental Control Profile : 64 • Maximum Parental Control Content Cilter Rule : 64 |
Guest Network | “The Guest Network provides Internet connection for guests but restricts access to your local network.” • Maximum Guest Network Rule : 2.4 GHz x 3, 5 GHz x 3 Guest Network Connection Time Limit Guest Network Encryption : Open system, WPA/WPA2/WPA3-Personal, WPS |
Security | AiProtection WPA3-Personal, WPA2-Personal, WPA-Personal, WPA-Enterprise , WPA2-Enterprise , WPS support WPS Let’s Encrypt DNS-over-TLS SSH Security Scan Firewall • Maximum Firewall Keyword Filter : 64 • Maximum Firewall Network Service Filter : 32 • Maximum Firewall URL Filter : 64 |
AiProtection | • Router Security Assessment • Malicious Site Blocking • Two-Way IPS • Infected Device Prevention and Blocking |
VPN | Instant Guard VPN Client L2TP VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion |
Traffic Control | Adaptive QoS • Bandwidth Monitor • Bandwidth Limiter — Maximum Bandwidth Limiter Rule : 32 Traditional QoS — Maximum Traditional QoS Rule : 32 Traffic Monitor • Real-time Traffic Monitor • Wired Traffic Monitor • Wireless Traffic Monitor Traffic Analyzer • Traffic Analysis Period : Daily, Weekly, Monthly • Website History |
WAN | Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP Dual WAN 3G / 4G LTE dongle Port forwarding • Maximum Port Forwarding Rule : 64 Port triggering • Maximum Port Triggering Rule : 32 DMZ DDNS NAT Passthrough : PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, SIP Passthrough, PPPoE relay |
LAN | DHCP Server IGMP Snooping IPTV LAN Link Aggregation Manually Assign IP Address • Maximum Manually Assign IP Address Rule : 64 Wake on LAN (WOL) |
Wireless | MU-MIMO UTF-8 SSID WiFi MAC Address Filter • Maximum MAC Filters : 64 Wireless Scheduler Airtime Fairness RADIUS Client Universal Beamforming Explicit Beamforming |
USB application | File System : HFS+, NTFS, vFAT, ext2, ext3, ext4 Safely Remove Disk AiCloud Download Master AiDisk Media Server Samba Server FTP Server Shared Folder Privileges |
Administration | Configuration Backup and Restore Diagnosis tools Feedback System System Log New Device Connect Notification Login Captcha Connection Diagnosis Auto Firmware Update |
