Model | Game Squid R1 |
| PSU form factor | ATX |
| Motherboard | ATX, Micro ATX, Mini-ITX |
| Case size (L x W x H) | 365*200*455mm |
| Carton size (L x W x H) | 490*247*420mm |
| Material | Hardware metal 0.5mm SPCC black coating Front panel: ABS+ mesh Left side tempered glass, Right side panel with metal |
| Weight (kg) | NW/GW: 4.10kg /4.80kg |
| Color option | Black/ White |
| USB+Audio Port | 1*USB3.0 + 2*USB1.0 + HD Audio |
| Detailed Configuration | 2*HDD + 3*SSD |
| Expansion slots | 7 slots |
| Fan | Front: 3*120mm (available) Top: 2*120mm (option), Rear:1*120mm (option) |
| Raditor | Front: 240mm |
| Graphics card | 310mm |
| Cooling | 159mm |
| Dust Filter | Top |
| Acessories | Screw bag |
