KEY SPECS
Motherboard Support:Mini-ITX, Micro-ATX, ATX
Enclosure Type:Mid-Tower
Case Material:SGCC Steel, Tempered Glass
DIMENSIONS
Height:495mm (With Feet)
Width:290mm
Depth:466mm
Weight:12.1 kg
COMPATIBILITY & CLEARANCE
Max CPU Cooler Clearance:Up to 165mm
Max GPU Clearance:Up to 435mm
PSU Clearance:200mm
Cable Management:91mm
FRONT I/O PORTS
USB 3.2 Gen 1 Type-A:2
USB 3.2 Gen 2 Type-C:1
Headset Audio Jack:1
EXPANSION SLOTS
Standard:7
Vertical:0
DRIVE BAYS
2.5":4+2
3.5":2
FAN SUPPORT
Side:3 x 120mm
Top:3 x 120mm / 2 x 140mm
Bottom:3 x 120mm / 2 x 140mm
Rear:1 x 120mm
Filters:All Air Intakes
RADIATOR SUPPORT
Side:Up to 360mm with Push/Pull
Top:Up to 360mm
Bottom:Up to 360mm
Rear:Up to 120mm
FAN SPECS
Model:F120Q (Case Version)
Speed:1200 ± 240RPM
Airflow:62.18 CFM
Static:1.05 mm - H2O
Noise:25.1 dBA
Fan Connector:3-pin
GENERAL
Warranty:2 Years
Model Number:CM-H91FW-01 (White) / CM-H91FB-01 (Black)
UPC:810074842495 (White) / 810074842488 (Black)
EAN:5056547202419 (White) / 5056547202402 (Black)
