Model
ROG STRIX 1000W Gold Aura Edition
Intel Form Factor
ATX12V
ATX 3.0
Yes
Kích thước
180x150x86mm
Efficiency
80Plus Gold
Chuẩn bảo vệ
OPP/OVP/UVP/SCP/OCP/OTP
Vật liệu
ROHS
Điện áp đầu vào
100-240Vac
DC Output Voltage
+3.3V +5V +12V -12V +5Vsb
Maximum Load
22A 22A 83.3A 0.3A 3A
Combined Load
120W 120W 996.6W 3.6W 15W
Total Output
1000W
Kết nối
- MB 24/20-pin x 1
- CPU 4+4-pin x 2
- PCI-E 16-pin x 1
- PCI-E 8-pin x 4
- SATA x 5
- PERIPHERAL x 4
Bên trong hộp
- Power Cord x 1
- Motherboard Power Cable x 1 (600mm)
- CPU Cable x 2 (650mm)
- PCI-E Gen 5 16-pin Cable x 1 (700mm)
- PCI-E 1-to-1 Cable x 2 (700mm)
- PCI-E 1-to-2 Cable x 1 (700mm)
- SATA 1-to-2 Cable x 1 (400+120mm)
- SATA 1-to-3 Cable x 1 (400+120+120mm)
- Peripheral 1-to-4 Cable x 1 (400+150+150+150mm)
- Addressable RGB Cable x 1 (800mm)
- User Manual x 1
Trọng lượng
3.03 kg (single PSU)
AURA SYNC
ARGB
0dB Fan Button
Yes
Cybenetics Noise Level Certification
A+
