General
- Form Factor: ATX12V
- Power Delivery: 1200W
- Dimensions: 180 x 150 x 86 mm (L x W x H)
- Weight: 3.23 kg
- Efficiency: 80 Plus Gold Certified (Up to 92% efficiency)
- ATX 3.0 Standard: Yes
- AURA SYNC: Yes (ARGB Support)
Input
- AC Input Range: 100-240Vac
- Power Factor Correction (PFC): Active PFC
Output
- DC Output Voltage: +3.3V, +5V, +12V, -12V, +5Vsb
- Maximum Load: +3.3V (22A), +5V (22A), +12V (100A), -12V (0.3A), +5Vsb (3A)
- Combined Load: +3.3V & +5V (120W), +12V (1200W), -12V (3.6W), +5Vsb (15W)
Protection Features
- Over Power Protection (OPP)
- Over Voltage Protection (OVP)
- Under Voltage Protection (UVP)
- Short Circuit Protection (SCP)
- Over Current Protection (OCP)
- Over Temperature Protection (OTP)
Environmental
- Cybenetics Noise Level Certification: A+
- 0dB Technology: Fan turns off under low load for silent operation
Compliance
- RoHS Compliant
Connectors
- Motherboard: 24/20-pin x 1
- CPU: 4+4-pin x 2
- PCI-Express (PCI-E):
- 16-pin x 1 (both PSU and component side)
- 8-pin x 4
- SATA: x 5
- Peripheral: x 4
Package Contents
- Power Cord x 1
- Motherboard Power Cable (600mm) x 1
- CPU Cable (650mm) x 2
- PCI-E Gen 5 16-pin Cable (675mm) x 1
- PCI-E 1-to-1 Cable (675mm) x 2
- PCI-E (16-pin to 8-pin-8-pin) Cable (675mm) x 1
- SATA 1-to-2 Cable (400+120mm) x 1
- SATA 1-to-3 Cable (400+120+120mm) x 1
- Peripheral 1-to-4 Cable (400+150+150+150mm) x 1
- Addressable RGB Cable (800mm) x 1
- User Manual x 1
