| P/N | PS-SPD-0750NNFABx-1 |
|---|
| WATTS | 750W |
|---|
| RGB FAN | No |
|---|
| FORM FACTOR | ATX |
|---|
| MODEL | SPD-750AH2NKB | SPD-750AH2NLB | SPD-750AH2NCB |
|---|
| TYPE | ATX 12V v2.3 and EPS v2.92 |
|---|
| MAX. OUTPUT CAPACITY | 750W |
|---|
| COLOR | Black |
|---|
| DIMENSION ( W / H / D ) | 150mm(W) x 86mm(H) x 140mm(D) |
|---|
| PFC (POWER FACTOR CORRECTION) | Active PFC |
|---|
| POWER GOOD SIGNAL | 100-500 msec |
|---|
| HOLD UP TIME | > 16msec at 70% of full load |
|---|
| INPUT CURRENT | 12A max. | 6 – 15A | 10A max. |
|---|
| INPUT FREQUENCY RANGE | 50Hz - 60Hz | 47Hz - 63Hz | 47Hz - 63Hz |
|---|
| INPUT VOLTAGE | 100V – 240V~ |
|---|
| OPERATING TEMPERATURE | 5°C to + 40°C | 5°C to + 40°C | 0°C to + 40°C |
|---|
| OPERATING HUMIDITY | 20% to 85%, non-condensing | 20% to 85%, non-condensing | 20% to 90%, non-condensing |
|---|
| STORAGE TEMPERATURE | -40°C to + 55°C | -40°C to + 55°C | -40°C to + 70°C |
|---|
| STORAGE HUMIDITY | 10% to 95%, non-condensing | 10% to 95%, non-condensing | 5% to 95%, non-condensing |
|---|
| COOLING SYSTEM | 12cm Hydraulic bearing fan |
|---|
| EFFICIENCY | Meet 80 PLUS®Bronze at 115Vac input. |
|---|
| MTBF | 100,000 hrs minimum |
|---|
| SAFETY APPROVAL | CE/CB/TUV/ UL/ FCC/ BSMI |
|---|
| PCI-E 6+2PIN | 4 |
|---|
