Nhà sản xuất | Sapphire |
GPU | AMD Radeon™ RX 7800 XT Graphics Card |
Engine Clock | Boost Clock: Up to 2565 MHz Game Clock: Up to 2254MHz |
Stream Processors | 3840 |
Compute Units | 60 CU (with RT+AI Accelerators) |
Bộ nhớ đệm | 64MB |
Gia tốc | 60 |
Memory Size/Bus | 16GB/256 bit GDDR6 |
Memory Clock | 19.5 Gbps Effective |
Hiển thị | Maximum 4 Displays |
Resolution | HDMI™: 7680×4320 DisplayPort 2.1: 7680×4320 |
Giao diện | PCI-Express 4.0 x16 |
Cổng ra | 2x HDMI 2x DisplayPort |
BIOS Hỗ trợ | Dual UEFI |
Game Index | 4K |
Tính năng | Dual BIOS TriXX Software Switch Premium Digital Power Design Ultra High Performance Conductive Polymer Aluminum Capacitors Fuse Protection Tri-X Cooling Technology High TG Copper PCB Optimized Composite Heatpipe Intelligent Fan Control Precision Fan Control Metal Backplate with ARGB ARGB Light Bar Two-Ball Bearing Fans Angular Velocity Fan Blade Assistive System Fan Control Aluminum Alloy Frame Dedicated VRM Cooling Wave Fin Design V Shape Fin Design for GPU Cooling TriXX Supported Fan Check Fan Quick Connect TriXX Boost NITRO Glow External RGB LED MB Synchronization |
Phụ kiện đi kèm | Graphics Card Supporter ARGB Extension Cable |
Tính năng | AMD RDNA™ 3 Architecture 54 AMD RDNA™ 3 Compute Units 48MB AMD Infinity Cache™ Technology DisplayPort™ 2.1 Support AMD Radiance Display™ Engine 12GB GDDR6 on 192-Bit Memory Bus PCI® Express 4.0 ready AMD FidelityFX™ Super Resolution technology* Microsoft® DirectX® 12 Ultimate Support Microsoft® DirectStorage Support Vulkan® Optimized AMD Smart Technologies AMD Software: Adrenalin Edition™ AMD Noise Suppression AMD Privacy View AMD Radeon™ Super Resolution technology AMD Link AMD FreeSync™ Technology |
Số quạt | 3 Fan |
Chuẩn | 3 slot, ATX |
Nguồn tiêu thụ | 288W Total Board Power |
Yêu cầu hệ thống | Minimum 700 Watt Power Supply 2 x 8-pin Power Connector. PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard. Minimum 8GB of system memory. 16GB recommended. |
